Building Your Own Super Computer

Building Your Own Super Computer




Why pay $10 million for a supercomputer when this article can show you how to build your own supercomputer cluster with just a handful of Windows/LinuxPC's...



James Cameron’s Titanic (the movie) special effects crew couldn't afford a supercomputer to do the critical rendering, and anything less would take far too long.
Like all high-end animators and special effects houses, the Titanic team had a slew of SGI Indigo workstations (as well as a pile of new Windows NT workstations for the low end jobs), but Titanic romance and tragedy was far more demanding than most projects.
A much greater degree of realism was required than for the typical science fiction epic, and realism is expensive. Rendering the water scenes was obviously a job for a supercomputer, but with Titanic already far over budget, a $10,000,000 computer wasn't realistic.


The performance problem was solved by assembling a cluster of DEC Alpha based computers into a Linux cluster, an instant supercomputer at a small fraction of the cost, which produced a large number of extraordinarily challenging visual effects for this demanding film.
In this article, although a bit off topic, I will discuss how to build a generic Linux or Windows supercomputer with the clustered computing concept. You will find out just how easy it is to build a supercomputer with Linux clusters. In this article we will limit our discussion to building Linux and Windows clusters to obtain supercomputer computational power. It is out of scope of this article to discuss how to solve any computational intensive algorithmic problem and how to code those algorithms for cluster architecture.




Building Your Own Super Computer - Definitions and Benefits of Clustering




Greg Pfister, in his wonderful book In Search of Clusters, defines a cluster as "a type of parallel or distributed system that: consists of a collection of interconnected whole computers, and is used as a single, unified computing resource".
Therefore, a cluster is a group of computers bound together into a common resource pool. A given task can be executed on all computers or on any specific computer in the cluster. Lets look into the benefits of clustering:



  • Scientific applications: Enterprises running scientific applications on supercomputers can benefit from migrating to a more cost effective Linux cluster .
  • Large ISPs and E-Commerce enterprises with a large databaseInternet service providers or e-commerce web sites that require high availability and load balancing and scalability.
  • Graphics rendering and animation: A Linux cluster has become important in the film industry for rendering quality graphics. In the movie Titanic, a Linux cluster was used to render the background in the ocean scenes. The same concept was used in the movies True Lies and Interview with the Vampire.

We can also characterize clusters by their function:

  • Distributed processing cluster: Tasks (small piece of executable code) are broken down and worked on by many small systems rather than one large system, often deployed for a task previously handled by supercomputers. This type of cluster is very suitable for scientific or financial analysis.

  • Fail-over clusters: Clusters are used to increase the availability and serviceability of network services. When an application or server fails, its services are migrated to another system. The identity of the failed system is also migrated. Failover servers are used for database servers, mail servers or file servers:

  • High availability load balancing clusters: A given application can run on all computers and a given computer can host multiple applications. The “outside world” interacts with the cluster and individual computers are “hidden”. It supports large cluster pools and applications do not need to be specialized. High availability clustering works best with stateless application and those that can be run concurrently:


Building Your Own Super Computer - Building Windows Clusters Hardware



Before starting, you should have the following hardware and software:

  • At least two computers with Windows XP, Windows NT, SP6 or Windows 2000 networked with some sort of LAN equipment (hub, switch etc.).

  • Ensure during the Windows set up phase that TCP/IP, and NETBUI are installed, and that the network is started with all the network cards detected and the correct drivers installed.


We will call these two computers a Windows cluster. You now you need some sort of software that will help you to develop, deploy and execute applications over this cluster. This software is the core of what makes a Windows cluster possible.


The Message Passing Interface (MPI) is an evolving de facto standard for supporting clustered computing based on message passing. There are several implementations of this standard.


In this article, we will use mpich2, which is freely available and you can download it From HERE for Windows clustering, and find related documentation here . Please read the Guide before starting the following steps.


Step 1: Download and unzip mpich2 into any folder and share this folder with write permission.

Step 2: Copy all files with the .dll extension from C:\MPICH2\lib to the C:\Windows\system32 folder.

Step 3: Install the Cluster Manager Service on each host you want to use for remote execution of MPI processes. For installation, start rcluma-install.bat (located in the C:\MPICH2\bin directory) by double-clicking from the local or network-drive. You must have administrator rights on the hosts to install this service.

Step 4: Follow step 1 and 2 for each node in the cluster (we will name each computer in the cluster as node).


Step 5: Now Start RexecShell  (from folder C:\MPICH2\bin) by double-clicking it:















Open the configuration dialog by pressing F2. The distribution contains a precompiled example MPI program named cpi.exe (located in MPICH2/bin). Choose it as the actual program. Make sure that each host can reach cpi.exe at the specified path.


Choose ch_wsock as the active plug-in. Select the hosts to compute on. On the tab 'Account', enter your username, domain and password, which need to be valid on each host chosen. Press OK to confirm your selections. The Start Button (from the Window RexecShell) is now enabled and can be pressed to start cpi.exe on all chosen hosts. The output will be displayed in separate windows.


Congratulations -- your supercomputer (Windows cluster) is ready to run MPI programs!

Building Your Own Super Computer - Building a Linux Cluster




Linux clusters are generally more common, robust, efficient and cost effective than Windows clusters. We will now look at the steps involved in building up a Linux cluster. For more information go HERE.


Step 1 :  Install a Linux distribution (I am using Red Hat 7.1 and working with two Linux boxes) on each computer in your cluster. During the installation process, assign hostnames and of course, unique IP addresses for each node in your cluster.
Usually, one node is designated as the master node (where you'll control the cluster, write and run programs, etc.) with all the other nodes used as computational slaves. We name one of our nodes as Master and the other as Slave.
Our cluster is private, so theoretically we could assign any valid IP address to our nodes as long as each has a unique value. I have used IP address 192.168.0.190 for the master node and 192.168.0.191 for the slave node.
If you already have Linux installed on each node in your cluster, then you don't have to make changes to your IP addresses or hostnames unless you want to. Changes (if needed) can be made using your network configuration program Linuxconf in Red Hat.
Finally, create identical user accounts on each node. In our case, we create the user DevArticle on each node in our cluster. You can either create the identical user accounts during installation, or you can use the adduser command as root.


Step 2 : We now need to configure rsh on each node in our cluster. Create .rhosts files in the user and root directories. Our .rhosts files for the DevArticle users are as follows:



  • Master DevArticle
  • Slave DevArticle




Moreover, the .rhosts files for root users are as follows:



  • Master root
  • Slave root




Next, we create a hosts file in the /etc directory. Below is our hosts file for Master (the master node):


192.168.0.190   Master.home.net Master

127.0.0.1          localhost


192.168.0.191   Slave



Step 3 : Do not remove the 127.0.0.1 localhost line. The hosts.allow files on each node was modified by adding ALL+ as the only line in the file. This allows anyone on any node permission to connect to any other node in our private cluster. To allow root users to use rsh, I had to add the following lines to the /etc/securetty file:

rsh, rlogin, rexec, pts/0, pts/1.

Also, I modified the /etc/pam.d/rsh file:

#%PAM-1.0
# For root login to succeed here with pam_securetty, "rsh" must be
# listed in /etc/securetty.



auth       sufficient   /lib/security/pam_nologin.so

auth       optional     /lib/security/pam_securetty.so


auth       sufficient   /lib/security/pam_env.so


auth       sufficient   /lib/security/pam_rhosts_auth.so


account  sufficient   /lib/security/pam_stack.so service=system-auth


session   sufficient   /lib/security/pam_stack.so service=system-auth


Step 4 : Rsh, rlogin, Telnet and rexec are disabled in Red Hat 7.1 by default. To change this, I navigated to the /etc/xinetd.d directory and modified each of the command files (rsh, rlogin, telnet and rexec), changing the disabled = yes line to disabled = no.
Once the changes were made to each file (and saved), I closed the editor and issued the following command: xinetd –restart -- to enable rsh, rlogin, etc.


Step 5 : Next, download the latest version of MPICH (UNIX all flavors) to the master node from here. Untar the file in either the common user directory (the identical user you established for all nodes "DevArticle" on our cluster) or in the root directory (if you want to run the cluster as root).


Issue the following command:


tar zxfv mpich.tar.gz




Change into the newly created mpich-1.2.2.3 directory. Type ./configure, and when the configuration is complete and you have a command prompt, type make.
The make may take a few minutes, depending on the speed of your master computer. Once make has finished, add the mpich-1.2.2.3/bin and mpich-1.2.2.3/util directories to your PATH in .bash_profile or however you set your path environment statement.
The full root paths for the MPICH bin and util directories on our master node are /root/mpich-1.2.2.3/util and /root/mpich-1.2.2.3/bin. For the DevArticle user on our cluster, /root is replaced with /home/DevArticle in the path statements. Log out and then log in to enable the modified PATH containing your MPICH directories.


Step 6 : Next, make all of the example files and the MPE graphic files. First, navigate to the mpich-1.2.2.3/examples/basic directory and type make to make all the basic example files.
When this process has finished, you might as well change to the mpich-1.2.2.3/mpe/contrib directory and make some additional MPE example files, especially if you want to view graphics.

Within the mpe/contrib directory, you should see several subdirectories. The one we will be interested in is the mandel directory. Change into the mandel directory and type make to create the pmandel exec file. You are now ready to test your cluster.

Building Your Own Super Computer - Testing Your Linux Cluster




The first program we will run is cpilog. From within the mpich-.2.2.3/examples/basic directory, copy the cpilog exec file (if this file isn't present, use make command again) to your top-level directory. On our cluster, this is either /root (if we are logged in as root) or /home/DevArticle, if we are logged in as DevArticle (we have installed MPICH both places).


Next, from your top directory, rcp the cpilog file to each node in your cluster, placing the file in the corresponding directory on each node. For example, if I am logged in as DevArticle on the master node, I'll issue rcp cpilog Slave:/home/ DevArticle to copy cpilog to the DevArticle directory on Slave. I'll do the same for each node (if there are more than two nodes). If I want to run a program as root, then I'll copy the cpilog file to the root directories of all nodes on the cluster.
Congratulation your supercomputer (Linux cluster) is ready to run MPI programs!


Once the files have been copied, I'll type the following from the top directory of my master node to test my cluster:

mpirun -np 1 cpilog


This will run the cpilog program on the master node to see if the program works correctly. Some MPI programs require at least two processors (-np 2), but cpilog will work with only one. The output looks like this:

pi is approximately 3.1415926535899406,
Error is 0.0000000000001474
Process 0 is running on Server.home.net
wall clock time = 0.360909



Now try all two nodes (or however many you want to try) by typing: mpirun -np 2 cpilog and you'll see something like this:


pi is approximately 3.1415926535899406,
Error is 0.0000000000001474
Process 0 is running on Master.home.net
Process 1 is running on Slave.home.net
wall clock time = 0.0611228



The number following the -np parameter corresponds with the number of processors (nodes) you want to use in running your program. This number may not exceed the number of machines listed in your machines.LINUX file plus one (the master node is not listed in the machines.LINUX file).


To see some graphics, we must run the pmandel program. Copy the pmandel exec file (from the mpich-1.2.2.3/mpe/contrib/mandel directory) to your top-level directory and then to each node (as you did for cpilog). Then, if X isn't already running, issue a startx command.

From a command console, type xhost + to allow any node to use your X display, and then set your DISPLAY variable as follows:

DISPLAY=Server:0 (be sure to replace Server with the hostname of your master node). Setting the DISPLAY variable directs all graphics output to your master node


Run pmandel by typing: mpirun -np 2 pmandel


The pmandel program requires at least two processors to run correctly. You should see the Mandelbrot set rendered on your master node.






Adding more processors (mpirun -np 10 pmandel) should increase the rendering speed dramatically. The mandelbrot set graphic has been partitioned into small rectangles for rendering by the individual nodes. You can actually see the nodes working as the rectangles are filled in. If one node is a bit slow, then the rectangles from that node will be the last to fill in. It is quite fascinating to watch.
